Fuzion NXWood Pro Dawnwood Luxury Vinyl Plank
Enter the size of your space
Enter the size of your space
Choose how you'd like to proceed
For this product only • No payment required
Add multiple items and request a quote together
Product Information
| Brand | Fuzion |
| Collection | NXWood Pro |
| Name | Dawnwood |
| SKU | NXP236DW02 |
| Product Type | Luxury Vinyl Plank |
| Construction | Hybrid Resilient Flooring (NXCore non-PVC waterproof core) |
| Locking System | 5G click |
| Certification | FloorScore Certified, CARB II |
| Thickness mm | 10 |
| Thickness in | 3/8" |
| Width in | 9-1/4" |
| Width mm | 235 |
| Length in | 60" |
| Length mm | 1524 |
| Wear Layer Rating | AC4 / 20mil equivalent |
| Edge Finish | 3DGE painted bevel with nano sealed edge |
| Surface Texture | Real Touch Embossed in Register (EIR) |
| Installation | Floating click |
| Pieces Per Box | 6 |
| Suitable Location | On, above or below grade |
| Radiant Heat | Hydronic radiant heat approved |
| Temperature Range | -30°C to 80°C |
| Residential Warranty | Lifetime residential |
| Commercial Warranty | 10-year light commercial |
| Accessories | Stair Tread & Riser, Square Stair Nose, Reducer, T-Mold |
| Wear Layer Thickness | AC4 / 20mil equivalent |
| SQFT Per Box | 23.14 |
No documents available
Contact us for installation guides, warranty information, or technical specifications
Contact Support
About this product
Dawnwood from the Fuzion NXWood Pro collection is a hybrid resilient luxury vinyl plank flooring available at Squarefoot Flooring in Mississauga and Barrie. Fuzion NXWood Pro Dawnwood is built to 10 mm thickness with an AC4/20 mil equivalent wear layer, Real Touch EIR surface texture, 3DGE painted bevel edge with nano sealed edge, and 5G click system on a non-PVC NXCore waterproof core. NXWood Pro Dawnwood Fuzion steps up to a wide 9-1/4" x 60" plank format, hydronic radiant heat approved, FloorScore and CARB II certified, covering 23.14 sq ft per carton, and installs on, above, or below grade from -30°C to 80°C. Dawnwood delivers a warm pale first-light dawn-cream tone with natural fine EIR grain suited for morning-inspired and luminous everyday casual interiors. Backed by a lifetime residential and 10-year light commercial warranty. Matching stair tread & riser, square stair nose, reducer, and T-mold accessories are available. SKU: NXP236DW02.
